Electric Forklift Truck
Advantages:High stability and safety
- Cab design by SIP point , conforms to EN- ISO 5353, ensures compartment with great comfort and fatigue- free operating .
- Multifunction LCD digital display with digital service hour metre, battery discharge indicator, travel records, error code and warning displays. Provide fast and accurate monitoring truck status.
- Mast cylinder lowering with buffering system: shock absorber steering axle with low noise. All of seal kits imported from Japan (NOK), transmission and working system have low noise.
- With regenerative brake in reversing mode and regular brake pedal use, truck can be braked after foot leaving the pedal. reduce operator efforts and improve the brake life.
- The optional of third safety pedal to reduce the driving speed while stacking and steering application.
Ergonomics
- Wide view mast, clear visibility.
- Low height access step with wide steel non slip plate for easy entry and exit.
- Cowl-mounted hydraulic levers design offers big operation space.
- Adjustable tilt steering column offers the most comfortable operator position.
- Seat with safety belt and arm rest (The optional of Grammar or suspension type).
- High-friction brake shoes are free of asbestos.
- With reverse mirror, front work light and back work light group.
Easy maintenance
- Floor board are easily removed for quick service assess.
- Insulated battery cover gas-filled cylinders and easy to maintain.
- The lifting motor under the floorboard for easy maintenance.
| Model | FB30 | FB35 | |
| Power | electric | electric | |
| Operation type | seated | seated | |
| Capacity/rated load | Q(kg) | 3000 | 3500 |
| Load centre distance | c(mm) | 500 | 500 |
| Lift height | h3(mm) | 3000~7000 | 3000~7000 |
| Load distance, centre of drive axle to fork | x(mm) | 498 | 498 |
| Wheelbase | Y(mm) | 1700 | 1700 |
| Service weight (with battery) | kg | 4750 | 5050 |
| Axle loading, laden front/rear | kg | 7000/750 | 7750/800 |
| Axle loading, unladen front/rear | kg | 2250/2500 | 2250/2800 |
| Tyres type | pneumatic/solid | Pneumatic/solid | |
| Tyre size, front | mm | Ф710×220/Ф695×218 | Ф710X220/Ф695X218 |
| Tyre size, rear | mm | Ф590×175/Ф577×162 | Ф590X175/Ф577X162 |
| Wheels, number front rear(x=driven wheels) | 2×2 | 2×2 / 4X2 | |
| Tread, front | b10(mm) | 1000 | 1000 |
| Tread, rear | b11(mm) | 970 | 970 |
| Tilt of mast/fork carriage forward/backward | Grad | 6°~12° | 6°~12° |
| Height, mast lowered | h1(mm) | 2060-3670 | 2060-3670 |
| Free lift | h2(mm) | 0 | 0 |
| Height, mast extended | h4(mm) | 4250~8250 | 4250~8250 |
| Height of overhead guard(cabin) | h6(mm) | 2135 | 2135 |
| Seat height/stand height | h7(mm) | 1035 | 1050 |
| Overall length | l1(mm) | 3690 | 3690 |
| Length to face of forks | l2(mm) | 3650 | 2650 |
| Overall width | b1(mm) | 1220 | 1220 |
| Fork dimensions | s/e/l(mm) | 45/125/1070 | 50/125/1070 |
| Fork carriage DIN 15173,class/type A,B | 3A | 3A | |
| Fork-carriage width | b3(mm) | 1100 | 1100 |
| Ground clearance,laden,below mast | m1(mm) | 135 | 135 |
| Ground clearance,centre of wheelbase | m2(mm) | 150 | 150 |
| Aisle width for pallets 1000×1200 crossways | Ast(mm) | 4090 | 4090 |
| Aisle width for pallets 800×1200 lengthways | Ast(mm) | 4290 | 4290 |
| Turning radius | Wa(mm) | 2400 | 2400 |
| Internal turning radius | b13(mm) | 200 | 200 |
| Travel speed, laden/unladen | Km/h | 12/13 | 12/13 |
| Lift speed, laden/unladen | mm/s | 220/300 | 200/300 |
| Lowering speed, laden/unladen | mm/s | <600 | <600 |
| Max. drawbar pull, laden/unladen | N | 15650 | 15650 |
| Max.gradeability, laden/unladen | % | 13/15 | 13/15 |
| Acceleration time, laden/unladen | s | 5-6 | 5-6 |
| Battery voltage,nominal capacity K5 | V/Ah | 80/450 | 80/450 |
| Battery weight | Kg | 1250 | 1250 |
| Battery dimensions l/w/h | mm | 970x673x708 | 970x673x708 |
| Type of drive control | DC/AC | DC/AC | |
| Operating pressure for attachments | Mpa | 17.5 | 17.5 |
| Sound level at the driver’s ear acc.to DIN 12053 | dB(A) | <75 | <75 |
The data is based on the lifting height 3000mm; Lifting height from 3000mm to 6000mm are available;Electric controller selection (1)standard: Enpower (2)Option: Curtis, Inmotion, ZAPI.
* Option: Lithium battery 300AH (Charger 48V/100A) / 350AH (Charger 48V/100A)
Adobe premiere elements for mac free download. 400AH (Charger 48V/150A) / 500AH (Charger 48V/200A)
